Basic information
- 2 x 2200W air-cooled xenon lamps
- Exposure area 2310 cm2
- XenoLogicTM lamp operation technology for extended lamp life
- Touch screen with color display for monitoring and displaying test parameters
- Direct setting and control of radiation intensity (300-400 nm)
- Direct setting and control of black standard temperature (BST)
- Direct setting and control of chamber temperature (CHT)
- Direct setting and control of relative humidity
- Display of diagnostic messages
- Storage of 10 user-defined tests
- Multiple languages available: English, German, Italian, French, Spanish, Turkish, Dutch, Polish, Hungarian, Czech, Japanese, Korean, Chinese
- On the XENOSENSIV® RC-300-400 BST stand for measuring and controlling irradiance (in W/m²) in the wavelength range 300-400 nm and BST (°C) at sample level
- Selectable temperature control, either by chamber temperature (up to 65 °C) or by dual control: chamber temperature and black standard temperature (up to 115 °C) simultaneously.
- Fan-controlled temperature difference between BST and CHT
- Ultrasonic humidifier controlling relative humidity in the range of 10-75% (light cycle)
- Integrated 60 liter water tank for humidity control and sample atomization (automatic refill)
- Sample atomization system
- Rotating sample rack with 38 test positions (13.5 cm x 4.5 cm); 33 (10.0 cm x 6.8 cm); 22 (13.5 cm x 5.5 cm); 11 (29.5 cm x 7.0 cm)
- Pre-programmed light and weather standards
- External cylinder made of special UV glass
- UV-protected test chamber window
- Internal memory for storing test data
- Data output via memory card or RS232 serial interface
- Ethernet interface for XenoTouch plug-ins (remote control, e-mail service, online monitoring).
