Basic information
- Dimensions 90 x 91 x 172 cm
- Exposure area 79 x 39 cm (3000 cm2)
- 3 xenon lamps with 1700 W power, air-cooled
- Easy-to-use user interface with touch screen and 13 selectable languages
- Direct setting and control of radiation intensity at 300-400 nm or 340 nm
- Direct setting and control of black standard temperature (BST) or black panel temperature (BPT)
- Direct setting and control of chamber temperature (CHT)
- Direct setting of tolerance ranges for each test parameter for optimal test control
- Diagnostic message display
- 10 freely programmable tests with up to 12 phases
- Pre-programmed polymer and coating standards for quick start
- Horizontal exposure area 3000 cm² for 34 standard or multiple 3D samples
- Premium sunlight simulation based on CIE85 reference sun
- Lamp cartridge with aluminum reflector, lamp connection and filter hole
- External filter with IR-reflecting layer
- Irradiance range 30-65 W/m2 (300-400 nm); 0.26-0.62 W/m2 (340 nm)
- Measurement and control of CHT: max. 70 ºC (during light phase)
- Measurement and control of BST or BPT: max. 100 ºC (during light phase)
- BST sensor design according to ISO 4892-1
- 4Selectable temperature control either with CHT or dual control: CHT and BST (BPT) simultaneously
- Controlled temperature difference between CHT and BST (BPT)
- Ultrasonic humidification system for humidity control
- Sample atomization system with integrated 60 l water tank
- Sample test plane inclined by 5° for discharge of atomized water
- Access opening approx. 30 x 25 mm for connecting external sensors inside the test chamber
- Shutdown based on radiation, light exposure time or total operating time
- Advanced automatic start-up functions
- Data output via memory card or RS 232
- Internal memory for storing test data
- Ethernet interface for network connection.
- See optional software add-ons XenoTouch 1, 2 and 3 ("Remote control", "Email service", "Online monitoring").
